Estimate
Proposal #1009
Date: May 17, 2018
Expires: Jun 16, 2018

Proposed Product Specifications for Example Project

Prepared by Estimator: Shaun Podenak

Work Site Address
8267 Causeway Blvd, Suite B
Tampa, FL 33619


08 41 14.22 Thermally Broken Aluminum Storefronts, Non-Impact Resistant, for Insulated Glazing: Product Specifications

Specification: Exterior Storefront

Product System
Cardinal 451T Storefront
Series CF451T
Product Approval ID N/A

System Type
Thermally Broken Aluminum Storefronts, Non-Impact Resistant, for Insulated Glazing

Framing Finish
Clear, Class 2 Anodized

Typical Glass Type
Insulated

Glass Layers
Surface 1 & 2
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Tempered
  • Even Surface: Low-E
Surface 2-3
  • Air Spacer Type: Aluminum
  • Gas Fill Type: Air
  • Grid: No Grid
Surface 3 & 4
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Tempered
Quantity: 1
Opening Size: 120" x 112"

Elevation: Entrance

Series CF451TSpecification: Exterior StorefrontProposal #1009Door:100ARefer to door schedule
Quantity: 4
Opening Size: 48" x 60"

Elevation: Type A

Series CF451TSpecification: Exterior StorefrontProposal #1009
Quantity: 1
Opening Size: 96" x 60"

Elevation: Type B

Series CF451TSpecification: Exterior StorefrontProposal #1009
Quantity: 2
Opening Size: 96" x 120"

Elevation: Type C

Series CF451TSpecification: Exterior StorefrontProposal #1009

Components

Head
  • Cardinal AF12-4 Assembly Screws
  • Cardinal CF451-13T Jamb/Head
  • Cardinal GT-1 Joint Sealant Tape
  • View images of parts
AF12-4
CF451-6T
GT-1
Glass  (Glass Lite)
  • Cardinal GSK-1 Glazing Gasket (Standard)
  • Cardinal SB-3 Setting Block for 1" Glass
  • Glass: 1" Overall, 1/4" Temp X 1/2" Air X 1/4" CL Temp
  • View images of parts
GSK-1
SB-3
SN-68
Elevation
  • Backer Rod, Open Cell, 7/8" Diameter
  • Cardinal CF451-6T Sill Receptor
  • Cardinal ED-451 End Dam
  • Cardinal GT-1 Joint Sealant Tape
  • Caulking: Perimeter Sealant, Sausages (By Volume)
  • Tape: Masking Tape (for Caulk Joints)
  • View images of parts
7/8" Tundra Foam
CF451-6T
ED-451
GT-1
Dymonic FC
Masking Tape
Intermediate Horizontal  (Horizontal)
  • Cardinal AF12-4 Assembly Screws
  • Cardinal CF451-2T Sill/Horizontal
  • Cardinal CF451-3 Glass Stop
  • Cardinal GT-1 Joint Sealant Tape
  • View images of parts
AF12-4
CF451-2T
CF451-3
GT-1
Sill
  • Cardinal AF10-4 Sill to Receptor Screws
  • Cardinal AF12-4 Assembly Screws
  • Cardinal CF451-2T Sill/Horizontal
  • Cardinal CF451-3 Glass Stop
  • Cardinal GT-1 Joint Sealant Tape
  • View images of parts
AF10-4
AF12-4
CF451-2T
CF451-3
GT-1
Jamb
CF451-6T
Tapcon
High Load Heavy Mullion  (Mullion)
  • Cardinal CF451-21T High Load Mullion
  • Cardinal CF451-4T Vertical Filler
  • Fastener: Tapcon 1/4" Diameter, #3 Flat Head
  • View images of parts
CF451-21T
CF451-4T
Tapcon

08 41 26.50 Top and Bottom Captured, Channel Glazed Interior Systems: Product Specifications

Specification: Office Partitions

Product System
All-Glass, Top and Bottom Captured: U-Channel for Swinging Doors
U-Channel Framed, 1/2" Glass

System Type
Top and Bottom Captured Channel Glazed Systems for Interior Use

Framing Finish
Brushed Stainless, Brushed

Typical Glass Type
Monolithic

Glass Layers
Surface 1 & 2
  • Glass Thickness: 1/2"
  • Color: Clear
  • Heat Treatment: Tempered
Quantity: 3
Opening Size: 119.875" x 96"

Elevation: Type F

U-Channel Framed, 1/2" GlassSpecification: Office PartitionsProposal #1009
Quantity: 1
Opening Size: 166" x 120"

Elevation: Type G

U-Channel Framed, 1/2" GlassSpecification: Office PartitionsProposal #1009

Components

1/2" Tempered Glass, Polished Verticals  (Glass Lite)
  • CRL RG12100
  • CRL US Aluminum SB140 Setting block for 450 Storefront & 1" U-Channel
  • Glass Fabrication: 1/2" Thick Linear Machine Flat Polish by unit
  • Glass: 1/2" Tempered
  • View images of parts
Roll-in Gasket
Glass Setting Block
Flat Polished Edge
1" Sill Channel  (Continuous Sill)
Tapcon
WU3 Channel
WU3
2" Head Channel  (Continuous Head)
2" Channel
2" Channel

05 73 13.01 Dry Glazed Railing System for 1/2" Monolithic Glass: Product Specifications

Specification: Hand Rail

Product System
CRL Taper-Loc Railing for 1/2" Monolithic Glass
Taper-Loc Railing System for 1/2" Monolithic Glass, Standard Mount, Concrete Substrate

System Type
Dry Glazed Railing System for 1/2" Monolithic Glass

Framing Finish
Brushed Stainless, Brushed

Typical Glass Type
Monolithic

Glass Layers
Surface 1 & 2
  • Glass Thickness: 1/2"
  • Color: Clear
  • Heat Treatment: Tempered
Quantity: 1
Opening Size: 96" x 42"

Elevation: Balcony Railing

Taper-Loc Railing System for 1/2" Monolithic Glass, Standard Mount, Concrete SubstrateSpecification: Hand RailProposal #1009

Components

Elevation
  • Base Shoe: B5A Cladding, 20 ga / 0.035" cladding, 9/16" X 4-1/8"
  • Base Shoe: B5A End Cap
  • Base Shoe: B5A10D 2-1/2" X 4-3/16" Channel for 1/2" Monolithic Glass
  • Base Shoe: Vinyl for 1/2" Glass Base Shoes
  • Tape: Very Hi-Bond, Gray 0.045" X 3/4" X 108' Acrylic Adhesive Cladding Tape, Length
  • View images of parts
Cladding
B5A End Cap
B5A
Acrylic Foam Tape
1/2" Tempered Glass  (Glass Lite)
  • Glass: 1/2" Tempered
Installation Hardware  (Continuous Sill)
  • Base Shoe: Surface Mate One-Piece Curved Block for Bottom Mount Installations
  • Base Shoe: Taper-Loc: X Taper Set for 1/2" and 3/4" Monolithic Tempered Glass
  • Fastener: Expansion Anchor, Hilti M8 3-7/8" Expansion Anchor
  • View images of parts
AACS1
TL5X10
Vertical Edge Polish  (Mullion)
Flat Polished Edge
Vertical Edge Polish  (Jamb)
Flat Polished Edge
2" Diameter Cap Rail  (Continuous Head)
  • Dow Corning 995 by 10.3 Oz Cartridge
  • Hand Rail: 2" Diameter Cap Railing
  • Hand Rail: 2" Diameter Cap Railing End Cap
  • Hand Rail: Cap Rail Vinyl for 1/2" Glass
  • View images of parts
995
GR20_
2" Diameter Cap Rail End Cap
GR5PV

08 83 10.01 Wall Mounted Mirrors: Product Specifications

Specification: Fitness Room Mirrors

Product System
Wall Mounted Mirrors
Mirrored Wall Wrapped with J-Channel, Machine Polished Joints

System Type
Wall Mounted Mirrors

Framing Finish
Clear, Class 1 Anodized

Typical Glass Type
Monolithic

Glass Layers
Surface 1 & 2
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Annealed
  • Even Surface: Mirror
Quantity: 1
Opening Size: 400" x 72.5"

Elevation: Fitness Room Mirrors

Mirrored Wall Wrapped with J-Channel, Machine Polished JointsSpecification: Fitness Room MirrorsProposal #1009

Components

Mirror  (Glass Lite)
  • Glass: 1/4" Clear Mirror
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 60 Grit
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 120 Grit
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 220 Grit
  • Setting Block: Clear Plastic, 0.125" x 1/4" x 2"
5/8" Deep J-Channel  (Continuous Sill)
  • Fastener #10 X 1-1/2" Counter Sunk, Oval Head, #2 Phillips Drive
  • J-Channel, 5/8" Deep for 1/4" Mirror
  • View images of parts
Deep J-Channel
Mirror Elevation  (Elevation)
Gunther Ultra Bond
5/8" J-Channel Trim  (Continuous Head)
Deep J-Channel
5/8" J-Channel at Vertical Perimeter Edges  (Jamb)
Deep J-Channel
Flat Ground 220 Grit Hand Polished Vertical Edges  (Mullion)
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 60 Grit
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 120 Grit
  • Sand Paper: Silicone Carbide - 5" PSA Disc - 220 Grit

08 45 14.14 Curtain Walls: Fully-Captured Curtain Wall Systems for Insulating, Impact Resistant Glazing: Product Specifications

Specification: Impact Resistant Curtain Wall

Product System
Coral Series PW257 Captured Curtain Wall System
Coral PW257 Single or Multi Span
Product Approval ID 14495.1

System Type
Fully-Captured Curtain Wall Systems for Insulating, Impact Resistant Glazing

Framing Finish
Clear, Class 2 Anodized

Typical Glass Type
Insulated-Laminated

Glass Layers
Surface 1 & 2
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Tempered
  • Even Surface: Low-E
Surface 2-3
  • Air Spacer Type: Aluminum
  • Gas Fill Type: Air
  • Grid: No Grid
Surface 3 & 4
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Heat Strengthened
Surface 4-5
  • Interlayer Material: PVB
  • Interlayer Thickness: 0.090
  • Interlayer Color: Clear
Surface 5 & 6
  • Glass Thickness: 1/4"
  • Color: Clear
  • Heat Treatment: Heat Strengthened
Quantity: 1
Opening Size: 320" x 134"

Elevation: S.S. CW w/ 90 Degree Corner

Coral PW257 Single or Multi SpanSpecification: Impact Resistant Curtain WallProposal #1009

Components

Glass Type IB (0.090 Saflex PVB) Wet Glazed  (Glass Lite)
  • Coral NG-10 Exterior Glazing Gasket
  • Coral NG14 Interior Spacer Gasket
  • Coral SB18 Setting Block @ Sill & Horizontal (PW257)
  • Dow Corning 995 Sausages (by Volume)
  • Glass: 1-5/16" Overall: 1/4" Temp X 1/2" Air Space X 1/4" HS X 0.090 PVB X 1/4" HS
  • Tape: Masking Tape (for Caulk Joints)
  • View images of parts
NG10
NG14
SB18
995
Solarban 70
Masking Tape
PW650 W/O Steel  (Mullion)
  • Coral AS32 Fastener #12 X 1-1/4" HWH #3 Self Drill
  • Coral NG-10 Exterior Glazing Gasket
  • Coral NG-12 Pressure Bar Gasket (Isolator)
  • Coral PW202 Open Back Mullion Filler
  • Coral PW204 Pressure Bar (Spliceable)
  • Coral PW205 Face Cover
  • Coral PW650 Vertical Mullion
  • Coral SP211 Mullion Cap
  • Fastener #8 X 1/2" PPH
  • View images of parts
NG10
PW202
PW204-1
PW205
PW650
Fastener
Jamb, PW650/202  (Jamb)
  • Coral AS25 #12 x 3/4" HWH #3 Zinc Plated Self Drilling Screw
  • Coral NG-10 Exterior Glazing Gasket
  • Coral NG-11 Exterior Perimeter Gasket
  • Coral NG-12 Pressure Bar Gasket (Isolator)
  • Coral PW202 Open Back Mullion Filler
  • Coral PW204 Pressure Bar (Spliceable)
  • Coral PW205 Face Cover
  • Coral PW613 Pocket Filler for PW650 @ Jambs, Mill Finish
  • Coral PW650 Vertical Mullion
  • Coral SP211 Mullion Cap
  • Fastener #10 x 1/2" HH Self Drilling
  • Fastener #8 X 1/2" PPH
  • Fastener: 1/8" x 1/2" Spring Pin, 420 Stainless Steel
  • View images of parts
NG10
NG11
PW202
PW204-1
PW205
PW613
PW650
#10-16 X 1/2" HH, Self Drilling, Stainless
Fastener
Head
  • Butyl Tape: Black: 3/8" x 1/8", Length
  • Coral AS16 Fabrication Screw
  • Coral AS32 Fastener #12 X 1-1/4" HWH #3 Self Drill
  • Coral NG-11 Exterior Perimeter Gasket
  • Coral NG-12 Pressure Bar Gasket (Isolator)
  • Coral PW203 Head/Sill/Horizontal Trim
  • Coral PW204 Pressure Bar (Spliceable)
  • Coral PW205 Face Cover
  • Coral PW652 Head/Sill
  • Coral SP204 End Dam @ Captured Mullion
  • Fastener 1/4" -- 20 X 3" Bolt
  • Fastener Nut for 1/4" Diameter, 20 Threads Per Inch
  • Fastener Washer for 1/4" Bolt
  • Fastener: 1/8" x 1/2" Spring Pin, 420 Stainless Steel
  • View images of parts
AS16
NG11
PW203
PW204-1
PW205
PW652
90 Degree Corner Mullion w/ SR504  (Mullion)
  • Coral AS25 #12 x 3/4" HWH #3 Zinc Plated Self Drilling Screw
  • Coral NG-10 Exterior Glazing Gasket
  • Coral NG-12 Pressure Bar Gasket (Isolator)
  • Coral PW208 Female Half 90 Degree Corner
  • Coral PW209 Male Half 90 Degree Corner
  • Coral PW210 Interior Corner Trim
  • Coral PW654 Corner Pressure Bar
  • Coral PW656 Glazing Tee -- 90 Degree Corner
  • Coral PW658 1-5/16" Glazing Face Cover 90 degree outside corner
  • Coral SP211 Mullion Cap
  • Coral SR504 Steel Reinforcement
  • Fastener #8 X 1/2" PPH
  • Fastener: 1/8" x 1/2" Spring Pin, 420 Stainless Steel
  • View images of parts
NG10
PW208
PW209
PW210
PW654
PW656
PW658
Fastener

10 28 19.24 Swinging Shower Doors: Product Specifications

Specification: 3/8" Inline Shower

Product System
Frameless Shower Doors

System Type
Frameless Shower

Framing Finish
Paint, Polished

Typical Glass Type
Monolithic

Glass Layers
Surface 1 & 2
  • Glass Thickness: 3/8"
  • Color: Clear
  • Heat Treatment: Tempered
Quantity: 1
Opening Size: 60" x 76"

Elevation: Guest Bath

Specification: 3/8" Inline ShowerProposal #1009Door:GuestRefer to door schedule
